Image 3: Handlebar with Intuvia display and gearshifter with gear
indicator
63 Shift advice: higher gear
64 Shift advice: lower gear
65 Battery charge-control
indicator
66 USB port
67 USB port protective cap
68 Motor-output indicator
69 Assistance level indicator
70 Light indicator
71 i button
72 Bike lights button
73 Gear barrel adjuster
74 Text indication
75 Value indication
76 Roller brake barrel
adjuster
* There are regional and personal preferences regarding which
brake lever operates which brake. If you want the standard setup
changed please refer to your Urban Arrow dealer.
User manual
All manuals and user guides at all-guides.com
77 Grip shifter with gear
indicator
78 Rear brake (right)*
79 Stem
80 Handlebar
81 Front brake (left)*
82 Control unit
83 On/Off button
84 Reset button
85 Speed indication
86 - button
87 i button
88 + button
89 Walk button for push
assistance
Clock, speed and distance indicators Intuvia display
Speed Current speed
Clock Current time
Max. speed Maximum speed achieved since the last reset
Avg. speed Average speed achieved since the last reset
Trip time Trip time since the last reset
Range Estimated range of the available battery charge
(for constant conditions such as assistance level,
route profile, etc.)
Range Display of the total distance travelled with the
e-bike (cannot be reset)
Trip distance Distance covered since the last reset
