Image 1: General overview (side view)
1 Head tube
2 Ahead steering set
steering shaft
3 Foam box
4 Ahead steering set front
fork
5 Front light
6 Front reflectors
7 Steering shaft bearing
8 Rigid front fork
9 Axle nut
10 Front wheel (20")
11 Fender
12 Steering shaft
13 Kickstand
14 Steering column
15 Main frame connecting bolt 33
16 Pedals
17 Pedal crank arms
18 Sprockets
User manual
All manuals and user guides at all-guides.com
19 Chain guard
20 Drop out bolt
21 Pad
22 Rear wheel (26")
23 Ring lock including lock
rubbers
24 Rear light
25 Saddle with handle
26 Speed sensor
27 Speed sensor magnet
28 Speed sensor magnet bolt
29 Charger plug
30 Socket for mains
connection
31 Battery charger
32 Safety warnings
Power cord charger plug
34 Roller brake
35 Disc brake
36 Front axle of disc brake
wheel
