7.8 Connection HF-cable
7.8.1 Connection to the unit
The HF-cable is connected through connection point [12] to the unit by means of a screw thread
connection.
The length of the HF-cable is critical. Therefore only use the by Enraf-Nonius supplied cable.
7.8.2 Connection to the radiator
The HF-cable is connected to the radiator by means of a "fast" coupling.
081-400-095-4A_950+_EN
To plug on the connector
Push on connector
Check to ensure that connector is
secure
To unplug the connector
Pull back ring
Pull out connector
