TECHNISCHE SPEZIFIKATIoNEN

8.10 Ports PINoUT

Tabelle 14: USB A
Tabelle 15: USB A

8.10.1 CAN X2

Tabelle 16: CAN

78
PIN Signal USB A
1 +5 Vcc
2 USB Data -
3 USB Data +
4 GND
PIN Signal USB B
1 +5 Vcc
2 USB Data -
3 USB Data +
4 GND
PIN Signal
1 -
2 CAN_L
3 CAN_GND
4 -
5 CAN_SHLD
6 CAN_GND
7 CAN_H
8 -
9 CAN_V+
