KEB COMBIVERT F5 SERVO Installationsanleitung Seite 51

CP-Parameter
Value Function
63
64
65
66
70
73
74
Unlisted values are only for application mode
Switching level of CP.33 = 100; switching level of CP.34 = 4
1)
CP.35 Limit switch / stopping mode
This parameter determines the reaction of the drive to terminal X2A.14 (F) and/or X2A.15
(R), which are programmed as limit switches. The reaction of the drive is shown in the
table below.
CP.35 Display Response
CP.36 External Fault / stopping mode
With the external error monitoring external units can take direct influence on the drive.
This parameter determines the response of the drive to a signal at terminal X2A.12 (I3)
according to following table.
CP.36 Display Response
Downloaded from www.Manualslib.com
Absolut value ANOUT1 > switching level
Absolut value ANOUT2 > switching level
ANOUT1 > switching level
ANOUT2 > switching level
Driver voltage activ (safety relay)
Absolut active power > switching level
Active power > switching level
0 E.PRx Immediate disabling of modulation
Quick stopping / disabling of modulation after
1 A.PRx
reaching speed 0
2 A.PRx Quick stop / holding torque at speed 0
3 A.PRx Immediate disabling of modulation
Quick stopping / disabling of modulation after
4 A.PRx
reaching speed 0
5 A.PRx Quick stop / holding torque at speed 0
6 None No effect to the drive, fault is ignored !
0 E.PRx Immediate disabling of modulation
Quick stopping / disabling of modulation after
1 A.PRx
reaching speed 0
2 A.PRx Quick stop / holding torque at speed 0
3 A.PRx Immediate disabling of modulation
Quick stopping / disabling of modulation after
4 A.PRx
reaching speed 0
5 A.PRx Quick stop / holding torque at speed 0
6 None No effect to the drive, fault is ignored !
manuals search engine
1)
1)
1)
1)
1)
1)
Restart
Remove fault,
reset
Autoreset, if no fault
is present
Inapplicable
Restart
Remove fault,
reset
Autoreset, if no fault
is present
Inapplicable
GB - 25
