Instrumentenbrettkabel (Panelkabel) und PC-Kabel

Cockpit Panel Cable
SN10 Cockpit panel cabling
SN10 PC / GPS
Remote Control
1 12V SW
2 TX out
3 RX in
4
5 GND
6 5V
7 B
8 A
9
GND
black
cable
open end cables at the
cockpit panel connector
SN10 Cockpit panel cabling
SN10 PC / GPS
Remote Control
1 12V SW
2 TX out
3 RX in
4 REL SW
5 GND
6 5V
7 B
8 A
9 NMEA
open end cables at the
cockpit panel connector
Software Version 2.31
S/N xxx001 to S/N xxx099
Cockpit Panel
Connector
1
2
3
4
5
6
7
8
9
from S/N xxx100 up
Cockpit Panel
Connector
1
2
3
4
5
6
7
8
9
grey
cable
Handbuch vom 14-Jul-2007
Anhang D: Verkabelungspläne
PC Cabling
PC Connector
Cockpit Connector
1
2
3
4
5
6
7
8
9
Cockpit Connector
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
PC Connector
1
2
3
4
5
6
7
8
9
