Menu Parameter
einstellung
644 Logic 4
6441 L4 Expr ((1.2).3).4
6442 L4 Input 1 CA1
6443 L4 Op 1 &
6444 L4 Input 2 NOT1
6445 L4 Op 2 &
6446 L4 Input 3 Run
6447 L4 Op 3 .
6448 L4 Input 4 Off
6449 L4 Set Dly 0s
644A L4 Res Dly 0s
644B L4 Tmr Val 0s
650 Timers [650]
651 Timer 1
6511 Timer1 Trig Aus
6512 Timer1 Mode Aus
6513 Timer1Delay 0s
6514 Timer1 T1 0s
6515 Timer1 T2 0s
6516 Timer1Value 0s
652 Timer2
6521 Timer2 Trig Aus
6522 Timer2 Mode Aus
6523 Timer2Delay 0s
6524 Timer2 T1 0s
6525 Timer2 T2 0s
6526 Timer2Value 0s
653 Timer3
6531 Timer3 Trig Aus
6532 Timer3 Mode Aus
6533 Timer3Delay 0s
6534 Timer3 T1 0s
6535 Timer3 T2 0s
6536 Timer3Value 0s
654 Timer4
6541 Timer4 Trig Aus
6542 Timer4 Mode Aus
6543 Timer4Delay 0s
6544 Timer4 T1 0s
CG Drives & Automation, 01-7491-02r0
Modbus
Werks- Instance/ Profibus
Device Net slot/index
No.
31096 121/240
43483 170/132
43484 170/133
43485 170/134
43486 170/135
43487 170/136
43488 170/137
43489 170/138
43490 170/139
43491 170/140
43492 170/141
43493 170/142
43600 170/249
43601 170/250
43602 170/251
43603 170/252
43604 170/253
43605 170/254
43606 171/0
43607 171/1
43608 171/2
43609 171/3
43610 171/4
43611 171/5
43612 171/6
43613 171/7
43614 171/8
43615 171/9
43616 171/10
43617 171/11
43618 171/12
43619 171/13
43620 171/14
43621 171/15
EtherCAT
Profinet Feldbus
index
index format
(HEX)
2448 1096 UInt, 1=1
4D9B 19867 UInt
4D9C 19868 UInt
4D9D 19869 UInt
4D9E 19870 UInt
4D9F 19871 UInt
4DA0 19872 UInt
4DA1 19873 UInt
4DA2 19874 UInt
4DA3 19875 Long, 1=1s
4DA4 19876 Long, 1=1s
4DA5 19877 Long, 1=1s
4E10 19984 UInt
4E11 19985 UInt
4E12 19986 Long, 1=1s
4E13 19987 Long, 1=1s
4E14 19988 Long, 1=1s
4E15 19989 Long, 1=1s
4E16 19990 UInt
4E17 19991 UInt
4E18 19992 Long, 1=1s
4E19 19993 Long, 1=1s
4E1A 19994 Long, 1=1s
4E1B 19995 Long, 1=1s
4E1C 19996 UInt
4E1D 19997 UInt
4E1E 19998 Long, 1=1s
4E1F 19999 Long, 1=1s
4E20 20000 Long, 1=1s
4E21 20001 Long, 1=1s
4E22 20002 UInt
4E23 20003 UInt
4E24 20004 Long, 1=1s
4E25 20005 Long, 1=1s
Modbus
Notes
format
UInt
UInt
UInt
UInt
UInt
UInt
UInt
UInt
UInt
EInt
EInt
EInt
UInt
UInt
EInt
EInt
EInt
EInt
UInt
UInt
EInt
EInt
EInt
EInt
UInt
UInt
EInt
EInt
EInt
EInt
UInt
UInt
EInt
EInt
