Emotron FDU2.1 Betriebsanleitung Seite 244

Menu Parameter
einstellung
2728 Subnet Mask 255.255.255.0
2729 Gateway 192.168.1.3
272A WiFi Status OK
Bluetooth (BLE)
273
options [273]
2731 BluetoothID 0.0.0.0
2732 Paring Key 123456
274 Security [274]
2741 Sec. Mode Open
2742 Password Empty string
Process and
Application
300
Parameters
[300]
310 Set/View ref
Process Settings
320
[320]
321 Proc Source Speed
322 Proc Unit Off
323 User Unit 0
324 Process Min 0
325 Process Max 0
326 Ratio Linear
327 F(Val) PrMin Min
328 F(Val) PrMax Max
Start/Stop
330
settings [330]
331 Acc Time 10s
332 Dec Time 10s
333 Acc MotPot 16s
334 Dec MotPot 16s
240 Menüliste
Modbus
Werks- Instance/ Profibus
Device Net slot/index
No.
40259 157/223
40260 157/224
40261 157/225
40262 157/226
40263 157/227
40264 157/228
40265 157/229
40266 157/230
30054 117/218
42620 167/34
40267 157/231
40273 157/237
40274 157/238
42991 168/150
43302 169/206
43303 169/207
43304 169/208
43305 169/209
43306 169/210
43307 169/211
43308 169/212
43309 169/213
43310 169/214
43311 169/215
43312 169/216
43313 169/217
43314 169/218
43101 169/5
43102 169/6
43103 169/7
43104 169/8
EtherCAT
Profinet Feldbus
index
index format
(HEX)
4103 16643 UInt, 1=1
4104 16644 UInt, 1=1
4105 16645 UInt, 1=1
4106 16646 UInt, 1=1
4107 16647 UInt, 1=1
4108 16648 UInt, 1=1
4109 16649 UInt, 1=1
410A 16650 UInt, 1=1
2036 54 UInt
4A3C 19004 UInt, 1=1
410B 16651 UInt, 1=1
4111 16657 UInt
4112 16658 UInt
4BAF 19375 Long, 1=0.001
4CE6 19686 UInt
4CE7 19687 UInt
4CE8 19688 UInt
4CE9 19689 UInt
4CEA 19690 UInt
4CEB 19691 UInt
4CEC 19692 UInt
4CED 19693 UInt
4CEE 19694 Long, 1=0.001
4CEF 19695 Long, 1=0.001
4CF0 19696 UInt
4CF1 19697 Long, 1=1
4CF2 19698 Long, 1=1
4C1D 19485 Long, 1=0.01s
4C1E 19486 Long, 1=0.01s
4C1F 19487 Long, 1=0.01s
4C20 19488 Long, 1=0.01s
Modbus
Notes
format
UInt
UInt
UInt
UInt
UInt
UInt
UInt
UInt
UInt
UInt
UInt
UInt
UInt
EInt
UInt
UInt
UInt
UInt
UInt
UInt
UInt
UInt
EInt
EInt
UInt
EInt
EInt
EInt
EInt
EInt
EInt
