NOTICE!
Risk of damage!
Water that has penetrated the housing may cause a short
circuit, improper cleaning could damage the plunge saw.
- Do not wash the plunge saw and also do not spray it off
with a water jet.
- Never immerse the plunge saw in water.
- Make sure that no water penetrates the housing.
- Do not use any aggressive cleaners, or sharp or metallic
cleaning utensils such as knives, hard scrapers or similar.
They could damage the surfaces.
1. Clean the plunge saw directly after each use.
2. Keep the protective devices as free of dust and dirt as
possible.
3. Rub the plunge saw off with a clean cloth or blow it off
with low-pressure compressed air. Wear protective gog-
gles when using compressed air.
4. Use a damp cloth and a small amount of soft soap if it
is heavily soiled.
Proper, regular care is not only important for safe
use, but also helps to extend the service life of the
plunge saw.
Replacing the connector cord
If the mains connection line of the plunge saw is damaged, it
must be replaced by the manufacturer, its after sales support
or a similarly qualified person in order to prevent risks.
Checking the plunge saw
Regularly check the condition of the plunge saw. Among other
things, check to make sure:
- that the switches are not damaged,
- that the accessories are in proper condition,
- that the mains connection line and the mains plug are not
damaged,
- that the vents are unobstructed and clean. If applicable, use
a soft brush to clean them.
If you identify any damage, you must have the
plunge saw repaired by a specialist workshop to
prevent risks.

12. Storage

Store the device and its accessories in a dark, dry and
frostproof place that is inaccessible to children. The optimum
storage temperature is between 5 and 30˚C.
Store the electrical tool in its original packaging.
Cover the electrical tool in order to protect it from dust and
moisture.
Store the operating manual with the electrical
tool.

13. Electrical connection

The electrical motor installed is connected and
ready for operation. The connection complies with
the applicable VDE and DIN provisions. The cus-
tomer's mains connection as well as the extension
cable used must also comply with these regula-
tions.
Important information
In the event of an overloading the motor will switch itself
off. After a cool-down period (time varies) the motor can be
switched back on again.
Damaged electrical connection cable
The insulation on electrical connection cables is often dam-
aged.
This may have the following causes:
• Passage points, where connection cables are passed
through windows or doors.
• Kinks where the connection cable has been improperly
fastened or routed.
• Places where the connection cables have been cut due to
being driven over.
• Insulation damage due to being ripped out of the wall
outlet.
• Cracks due to the insulation ageing.
Such damaged electrical connection cables must not be used
and are life-threatening due to the insulation damage.
Check the electrical connection cables for damage regularly.
Make sure that the connection cable does not hang on the
power network during the inspection.
Electrical connection cables must comply with the applicable
VDE and DIN provisions. Only use connection cables with the
marking „H05VV-F".
The printing of the type designation on the connection cable
is mandatory.
AC motor
• The mains voltage must be 230-240 V~ 50 Hz.
• Extension cables up to 25 m length must have a cross sec-
tion of 1.5 mm .
2
Connections and repairs of electrical equipment may only be
carried out by an electrician.
Please provide the following information in the event of any
enquiries:
• Type of current for the motor
• Machine data - type plate

14. Disposal and recycling

The equipment is supplied in packaging to prevent it from
being damaged in transit. The raw materials in this packaging
can be reused or recycled. The equipment and its accessories
are made of various types of material, such as metal and
plastic. Defective components must be disposed of as special
waste. Ask your dealer or your local council.
IE/NI 37
