piece of scrap lumber.
(2) Adjust the guide clearance on the rail with the two adjust-
ment screws (9).
(3) Set the plunge saw to ca. 6mm cut depth
(4) Set up the saw at the back end of the rail.
(5) Switch on the machine, press down to the set cut depth
and fit the splinter guard along the whole length in one
pass without stopping. The edge of the splinter guard
now corresponds exactly to the cutting edge of the saw
blade
Cutting with guide rails (Fig. D, K)
(1) Place the machine in the guide rails.
(2) Turn on the machine by pressing the ON/OFF switch (8).
(3) Press the plunge-cut trigger (3).
(4) Press the saw downwards to reach the sawing depth.
During first use the rubber lip is sawn off and thus splitter
protection is guaranteed up to the saw blade.
(5) Push the saw uniformly forwards.
(6) Turn off the machine and tilt the saw blade to the top
when the saw cutting is complete.
Plunge Cuts with guide rails
(1) Set the saw on the guide rail at the marked cutting point
(2) Secure the rebound protection or fence (accessory not
included) at the back and front cut points on the guide
rail.
(3) Switch on the machine.
(4) Press the saw down slowly to the set cut depth and move
this forward evenly on the rail up to the front cutting
point.
Tilt Protection
For miter cuts, it is advisable to install a tilt protection.
This prevents the machine from tilting to one side while in an
oblique position.
Injuries to the body or damage to the machine can be
avoided thereby.
When you are finished cutting
1. First turn the plunge saw off and then the dust extractor.
The saw blade will continue to rotate for some time.
2. Remove the cutting waste from the saw blade when the
saw blade returns to the resting position.
3. Disconnect the plunge saw from the power supply by
pulling the mains plug out of the socket.
4. Let the plunge saw cool off completely.
Removing jammed material
WARNING!
Risk of injury!
Incorrect handling of the plunge saw poses a risk of serious
injury.
- Immediately switch the plunge saw off and pull the mains
plug out of the socket if the saw blade catches in the work-
piece or any other blockages occur.
- Use protective gloves. Do not touch the saw blade with your
bare hands.
36 IE/NI

10. Transport

1. Always switch off the electric tool before transport and
disconnect it from the power supply.
2. To transport the electric tool, lift it by the Handle/hand
grip.
3. Protect the electric tool against impacts, shocks and se-
vere vibrations, e.g. during vehicular transport.
4. Secure the electric tool against toppling and slipping.

11. Cleaning and maintenance

WARNING!
Prior to any adjustment, maintenance or service work discon-
nect the mains power plug!
General maintenance tasks
• To ensure constant air circulation, always keep the cooling
openings in the housing unobstructed and air accessible.
• Use an extractor on all the openings of the machine to
remove wood chips and splinters.
• Rub the device clean with a clean cloth or blow it off with
compressed air at low pressure.
• We recommend that you clean the device directly after
every use.
• Clean the device at regular intervals using a damp cloth
and a little soft soap. Do not use any cleaning products or
solvents; they could attack the plastic parts of the device.
Make sure that no water can penetrate the device interior.
• Oil the rotating parts once monthly to extend the life of the
tool. Do not oil the motor.
Carbon brushes
- If excessive sparks are generated, have an electrician check
the carbon brushes.
Important note! The carbon brushes must be replaced
by an electrician exclusively.
WARNUNG!
Risk of injury!
Incorrect handling of the plunge saw poses a risk of serious
injury.
- Before cleaning or maintenance, switch the plunge saw off
and pull the mains plug out of the mains socket.
- Wear suitable protective gloves when working on the plunge saw.
- There are no parts that can be repaired by the user inside
this plunge saw. Never attempt to repair the plunge saw
yourself. Always contact a qualified workshop for this.
WARNING!!
Burn hazard!
The saw blade may become hot during operation, you could
burn yourself on it.
- Always let the saw blade cool off completely before clean-
ing.
