Operating instructions
3.2.7

Electrically adjustable seating system (optional)

If your wheelchair is electrically adjustable, the following parts may be electrically adjusted, depending on your wheelchair model:
•
leg rests
•
back angle
•
tilting angle
•
seating height
The electrical adjustment is carried out using the knob on the controller and the joystick:
1. Select the part you wish to adjust by pressing the corresponding knob on the controller. The indicator light will go on to indicate
that the corresponding part has been selected, see Figure 19: The following parts may be adjusted:
indicator 1
indicator 2
indicator 3
indicator 4
indicator 5
indicator 6
2. Select the desired position for the part by pushing the joystick away from you (part will move downward or forward) or pulling it
towards you (part will move upward or back).
3.2.8

Comfort leg rests (optional)

The comfort leg rest
The comfort leg rest has a hinge point at knee height and can be adjusted using the gas spring.
1. Push handle A forward to unlock the gas spring.
2. Move your leg to the desired position.
3. Release the handle, which will lock the gas spring.
The electric comfort leg rest
See "Electrically adjustable seating system (optional)
3.2.9

Removing leg rest, arm rest, or leg rest

Swinging the leg rests aside and removing them:
1. Push handle A to the inside to unlock the leg rest (see Figure 15 above).
2. Swivel the leg rest aside.
3. If required, remove the leg rest by lifting it straight up.
Removing the arm rest:
18
Downloaded from www.Manualslib.com
both leg rests simultaneously
left-hand side leg rest
right-hand side leg rest
back angle
tilting angle
high/low adjustment
Figure 15
Figure 16
manuals search engine
handle A
knob A
