BMS-bus address ranges
Addresses* Device
0
1 PRC1470
1...30 IRDH275B/
375B/575
1...30 COM465
2...30 EDS47x-12
31...60 SMO480-12
61...90 EDS47xE-12 Insulation fault evaluators (localisation)
111...119 PGH47x
121...150 PGH47xE
72
Meaning
There is no device with address 0 !
Information sent to address 0 applies to all
devices connected to the interface (broadcast)
Control and indicating device
Insulation monitoring device
Protocol converter
Insulation fault evaluators (localisation)
Signal converter relay
Test device for insulation fault location
Test device for insulation fault location
Malfunctions due to wrong address assignment!
Assigning wrong addresses to external devices may cause
malfunctions. Assign the addresses in a way that there are
no gaps of more than five subsequent addresses (1...30,
31...60, 61...90, 111...119 and 121...151).
IRDH275_D00122_03_M_XXEN/05.2017
Serial interfaces
