■ Pull air micrometer [1-5] out of gun body.
■ Remove air piston with air piston spring.
■ Remove air piston rod [# 29629].
■ Use universal wrench to unscrew stuffing box [# 3749] and remove
from gun body.
■ Pull seal [# 422] out of gun body.
Installing the seal
■ Insert seal into gun body [# 422].
■ Use universal wrench to thread stuffing box [# 3749] and into gun
body.
■ Insert air piston rod into correct position.
■ Grease air piston with air piston spring [10-3] and air micrometer with
SATA gun grease (# 48173) and insert.
■ Press air micrometer into gun body.
■ Screw in locking screw.
■ Assemble the nozzle set (see 9.1).
■ Insert spring and paint needle.
■ Screw adjustment screw [1-4] with counter nut into gun body.
After assembly, set the material flow rate as instructed in Chapter 8.2.
9.6. Replacing the spindles of the round/flat fan control
Replacement is necessary if air escapes at the round/flat fan control or
adjustment of the fan pattern is no longer possible.
Remove spindle
■ Remove counter-sunk screw [# 1503].
■ Remove control knob [# 3657].
■ Use SATA universal wrench to unscrew complete spindle [# 54221]
and remove from gun body.
Attaching the spindle
■ Use SATA universal wrench to thread complete spindle [# 54221] into
gun body.
■ Attach control knob [# 3657.
■ Coat counter-sunk screw [# 1503] with Loctite 242 and screw in until
hand tight.

10. Care and Storage

Careful handling and regular care of the product are required to guaran-
tee the proper function of the paint spray gun.
■ Store the paint spray gun in a dry location.
