Operating instructions SATA anti-dust jet / SATA anti-dust jet X
EN EN
Weight
Dimensions
3.

Scope of Delivery

• SATA anti-dust jet / X / US / X US
• SATA anti-dust power
pack / X / US / X US
4.

Technical Design

4.1. SATA anti-dust jet / X [1]
[1-1] Rotating nozzle
[1-2] Trigger
[1-3] Closing screw
[1-4] Air piston (not visible)
[1-5] Closing cap with O-ring
[1-6] Locking screw of air closing
cap
[1-7] Spray gun body
4.2. SATA anti-dust power pack X / X US [2]
[2-1] Power plug (EU 230 V)
[2-2] Power cord/supply voltage
[2-3] SATA anti-dust power pack
housing
[2-4] Fuse
4 4
approx. 4 kg
230 x 140 x 82 mm
(US 110 V)
• Wall mounting kit
• Tool kit
• Operating Instructions
[1-8] Compressed air connection
[1-9] Corrugated hose clip
[1-10] Electrode plug
[1-11] Electrode cable
[1-12] Earthing cable
[1-13] Electrode
[1-14] Fixing panel
[2-5] ON/OFF switch (ON =
lighted)
[2-6] Earthing terminal
[2-7] High voltage connections
(5x)
[2-8] Dimensions
[2-9] Fixing clamps
