Technical data

3.1

General data

Model
Maximum power
Continuous power
Propulsive power
Comparable petrol engine
Weight including power electronics
(excluding batteries)
Protection class as per DIN EN 60529
Component
Charger unit
Connection box
Motor

High-voltage battery

Temperature sensor for gearbox
page 54 / 92
All manuals and user guides at all-guides.com
DEEP BLUE 80 DEEP BLUE 40
66 kW 33 kW
50 kW 25 kW
> 32.4 kW > 16.2 kW
80 HP 40 HP
88 kg 88 kg
Protection class
IP67
IP66
IP67
IP67
IP67
3.2

Weight DEEP BLUE system

Number of high-voltage batteries
With 1 high-voltage battery
With 2 high-voltage batteries
With 3 high-voltage batteries
With 4 high-voltage batteries
3.3 High-voltage battery
Parameter
Usable energy per
high-voltage battery
Capacity
Operating voltage
Weight
Permitted storage temperature
Optimum storage temperature
Operating temperature
Storage temperature
Technical data
Weight
261 kg
410 kg
559 kg
708 kg
Value/unit
12.8 kWh
40 Ah
345 V
149 kg
-40 °C ... +50 °C
<25 °C
-20 °C ... +55 °C
-20 °C ... +50 °C
