Ottobock Genium-Bionic Prosthetic System 3B1 Gebrauchsanweisung Seite 96

Environmental conditions
Long-term storage (>3 months)
Operation
Charging the battery
Product
Reference number
Mobility grade according to MOBIS
Maximum body weight
Protection class
Water resistance
Weight of the prosthesis without tube adapter
and Protective Cover
Tube adapter
Reference number
Weight
Material
Max. body weight
Protection rating
Prosthesis battery
Battery type
Charging cycles (charging and discharging
cycles) after which at least 80% of the original
battery capacity remains available
Charge level after 1 hour charging time
Charge level after 2 hours charging time
Charge level after 4 hours charging time
Charge level after 8 hours charging time
Product behaviour during the charging process The product is non-functional
Operating time of the prosthesis with new, fully
charged battery at room temperature
Power supply
Reference number
Storage and transport in original packaging
Storage and transport without packaging
Operation
Input voltage
Mains frequency
96
-20°C/-4°F to +20°C/+68°F
Max. 93% relative humidity, non-condensing
-10°C/+14°F to +60°C/+140°F
Max. 93% relative humidity, non-condensing
+10°C/+50°F to +45°C/+113°F
3B1/3B1=ST/3B1-2/3B1-2=ST
2 to 4
150 kg
IP54
Weatherproof, not corrosion-resistant
approx. 1,400 g
2R20
190-300 g/0.42-0.66 lbs
150 kg
Li-Ion
500
30 %
50 %
80 %
Fully charged
Approx. 5 days with average use
757L16*
-40 °C/-40 °F to +70 °C/+158 °F
-40 °C/-40 °F to +70 °C/+158 °F
10 % to 93 % relative humidity, non-condens­
ing
0 °C/+32 °F to +40 °C/+104 °F
max. 90 % relative humidity, non-condensing
100 V~ to 240 V~
50 Hz to 60 Hz
2R21 (with torsion unit)
435-545 g/0.96-1.20 lbs
Aluminium
125 kg
IP54
