P P r r o o d d u u c c t t f f u u n n c c t t i i o o n n s s
The graphical user interface shown is for reference only. The image shows where you will see the icons and buttons
illuminate when they are active. At no time will you see all of these icons at the same time.
B B u u t t t t o o n n s s
The buttons are located on the outside of the graphical user interface. They are visible when available.
I I c c o o n n N N a a m m e e
Stand-by
Therapy paused
View temperature
Lock / unlock screen
Audio paused
Automatic therapy mode
Manual therapy mode
Monitor only mode
EN 12
F F u u n n c c t t i i o o n n
Press and hold the button for two seconds to stop therapy or
power off
Press and hold the button for two seconds to pause or resume
therapy
Select temperature degree in Celsius or Fahrenheit
Press and hold the button for two seconds to lock or unlock the
graphical user interface
Pause or resume the audible indicator when an alarm is active.
Silences each alarm for 5, 10 or 30 minutes depending on the
alarm condition. This button breathes¹ to indicate that it is in a
paused state.
Cools or warms the patient to a selected patient target
temperature
Cools or warms the water to a selected water target temperature
Displays the current patient temperature (no therapy)
8001-109-005 Rev C.2
