WARNING:
The hydraulic pumps manufactured by Cembre S.p.A. have been developed to be
used with crimping or cutting heads. According to this specifi c use, they do not
need and they are not equipped with a safe oil non-return system.
For this reason, their use different from the application to which they have been
devoted (for example the supply of hydraulic jacks, of lifting systems or similar)
can be dangerous for the operator.
Cembre does not accept any liability arising from the use of our pumps for applica-
tions different from those listed in our catalogue or other information document.

1. GENERAL CHARACTERISTICS

– Air pressure: ........................................................................ 6 ÷ 8 bar
– Max operating pressure: ..................................................... 700 bar
– Dimensions: length (A) ....................................................... 320 mm
– Weight (complete with high pressure hose) .......................... 6,8 kg
– High pressure fl exible hose: length ................................ 2 m
– Oil reservoir capacity: ......................................................... 1400 cm
– Recommended oil: ............................... AGIP ARNICA 32
Coupler: the pump is delivered complete with a high pressure fl exible hose, with "self-
– Safety: the pump is provided with max pressure valve; MPC1 special manometer, is
Acoustic noise
(Directive 2006/42/EC, annexe 1, point 1.7.4.2 letter u)
– The weighted continuous acoustic pressure level equivalent
A at the work place L
– The maximum value of the weighted acoustic displacement
pressure C at the work place L
– The acoustic power level emitted by the machine
L is equal to ............................................................................................... 83,7 dB (A)
WA
25 2
AIR-HYDRAULIC PUMP
TYPE CPP-0
(Ref. to Fig. 1)
width (B) ....................................................... 150 mm
height (C) ....................................................... 200 mm
SHELL TELLUS OIL TX 32
lock" female quick coupler; suitable for connection to a Cembre hydraulic
crimping or cutting heads (see Fig. 2).
available upon request to check the proper setting of the valve.
is equal to ................................................................ 70,0 dB (A)
pA
is ....................................................... < 130 dB (C)
pCPeak
ENGLISH
(87 ÷ 115 psi)
(10,000 psi)
(12.6 in.)
(5.9 in.)
(7.9 in.)
(15 lbs)
(6.5 ft)
3
(1.3 gal)
or
or equivalent
