The battery pack will become slightly warm to the
Q
touch while charging. This is normal and does not
indicate a problem.
Do not place charger in an area of extreme heat or
Q
cold. It will work best at normal room temperature.
When batteries become fully charged, unplug charger
Q
from power supply and remove the battery pack.
OPERATING THE TRIMMER
See Figure 9~10b.
WARNING:
Always position the unit on the operator's right
side. The use of the unit on the operator's left
side will expose the user to hot surfaces and can
result in possible burn injury.
WARNING:
To avoid burns from hot surfaces, never operate
unit with the bottom of the engine above waist
level.
Hold the trimmer with your right hand on the rear/right
handle and your left hand on the other handle. Keep
a firm grip with both hands while in operation. The
brushcutter should be held at a comfortable position with
the rear handle about hip height.
Always operate brushcutter at full throttle. Cut tall grass
from the top down. This will prevent brush from wrapping
around the shaft housing and blade which could cause
damage from overheating. If grass becomes wrapped
around the cutting blade, stop the engine, disconnect the
spark plug lead, and remove the grass.
Prolonged cutting at partial throttle will result in lubricant
dripping from the muffler.
WARNING:
Always hold the brushcutter away from the
body keeping clearance between the body and
the product. Any contact with the housing or
brushcutter head can result in burns and/or
other serious personal injury.
CUTTING TIPS
When cutting make sure the cutter head is at a slight
angle as shown while still approximately parallel to the
ground surface. In tall grass cut from the top down to
ensure the moving parts do not get tangled with the long
grass / brush.
Move the head in steady strokes from left to right as you
work through the grass / brush.
ADVANCING THE LINE(Only for Reel easy trimmer
head) See figure 11
If the line becomes short, tap the head on the ground
as shown to extend more line. Take care not to 'crash' it
against a hard surface.
IT PT NL SV DA
English (original instructions)
NO FI HU CS RU
OPERATING THE BRUSHCUTTER
See Figures 9~10a.
RBC30SET
Hold the brushcutter with your right hand on the rear
handle and the your hand on the "J" handle. Keep a firm
grip with both hands while in operation.
Brushcutter should be held at a comfortable position with
the rear handle about hip height.
Maintain your grip and balance on both feet. Position
yourself so that you will not be drawn off balance by the
kickback reaction of the cutting blade.
Adjust the shoulder harness to position the brushcutter at
a comfortable operating position and to assure that the
shoulder harness will reduce the risk of operator contact
with the blade.
RBC30SBT
Hold the brushcutter with the right hand on the trigger
handle and the left hand on the left handle. Keep a firm
grip with both hands while in operation. Brushcutter
should be held at a comfortable position with the trigger
handle about hip height. Maintain your grip and balance
on both feet. Position yourself so that you will not be
drawn off balance by the kick-back reaction of the cutting
blade.
Adjust the shoulder strap to position the brushcutter at
a comfortable position and to assure that the shoulder
strap will reduce the risk of operation contact with the
blade.
BLADE THRUST
Exercise extreme caution when using the blade with this
unit.
Blade thrust is the reaction that may occur when the
spinning blade contacts anything it cannot cut.
This contact may cause the blade to stop for an instant,
and suddenly "thrust" the unit away from the object that
was hit.
This reaction can be violent enough to cause the
operator to lose control of the unit. Blade thrust can occur
without warning if the blade snags, stalls, or binds.
This is more likely to occur in areas where it is difficult to
see the material being cut.
For cutting ease and safety, approach the weeds being
cut with the brushcutter from the right to the left. In
the event an unexpected object or woody stock is en
countered, this practice could minimize the blade thrust
re action.
WARNING
To avoid burns from hot surfaces, never operate
unit with the bottom of the engine above waist
level.
