INTERCOM FUNCTION
1. Go to the monitor to be programmed as caller
(monitor 'a').
2. Hold the door opener button pressed and pick
up the handset. Monitor 'a' will beep twice to
indicate that it is in programming mode.
3. Press the button to be programmed. The
monitor will output a confi rmation tone. The
button may be "•", "A" or "B".
4. Go to the monitor to be called by pressing the
button ('b') and press the door lock release
button. The monitors will beep to indicate
that they have been programmed.
5. Hook up the handset of monitor "a". It will beep to indicate exit from programming mode.
6. Check the programmed function: pick up handset "a" and press the programmed button. Check that
monitor "b" rings and that audio connection may be established.
7. To program calling in the opposite direction, program monitor "b" to call monitor "a".
If button "•" is programmed for intercom function, the auto power-on and 'video transfer' functions will
be maintained because these are performed with the handset on-hook.
28
VIDEO DOORPHONE TONE
One of fi ve tones may be chosen for monitors installed on B-FAST brackets. The tone may be selected by the
"a"
user by means of the following simple sequence.
1.
2.
3.
FLOOR CALL OR INTERCOM CALL TONE
"a"
One of fi ve tones may be chosen for B-FAST monitors for fl oor calls. The tone may be selected by the user by
means of the following simple sequence.
1.
2.
3.
"b"
PROGRAMMED DATA CLEARING PROCEDURE
Proceed as follows to clear all optional programming data:
1.
2.
3.
DS90365-005 DS90365-005
Hold the door lock button pressed and release
button "A". The monitor call tone will be
played.
Hold the door lock release button pressed and
press button "A" again to change the tone.
Release the door lock release button when
you hear the tone you want. The tone will be
programmed.
Hold the door lock button pressed and release
button "•". The monitor call tone will be
played.
Hold the door lock release button pressed and
press button "•" again to change the tone.
Release the door lock release button when
you hear the tone you want. The tone will be
programmed.
Access programming mode as shown in the "Intercom function" paragraph.
Hold buttons A" and "•" pressed for three second until you hear a delete tone.
Release buttons "A" and "•" and hang up.
