ENGLISH
GENERAL FEATURES AND SYSTEM TYPES
The general features of the T-LINE B-FAST one-family kit are:
Two non-polarised wires for all parts of the system.
One centralised power supply unit allowing to connect two lines.
Simple installation.
Extension wiring via one-user distributor or in in-out mode directly to device terminals.
Management of one door panel.
Management of one user, with possibility of up to four monitors in parallel.
Other B-FAST devices may be connected to the video doorphone of the kit:
- 1 decoder with relay
- 3 video doorphones (b/w or colour) or doorphones
- 1 camera cycle module.
Standard fl oor call to monitor with different tone from video doorphone calls.
Surveillance camera auto power-on function, up to four cameras with camera cycle module.
Entirely free programmable intercom call to monitors.
Five tones selectable by user for fl oor calls and for door panel calls.
A self-powered ringer or a call repeater relay may be connected to the monitor.
SYSTEM AND KIT COMPONENTS
The system components differ according to the purchased kit. These are shown in the following table.
Description of the item
CODICE
T-LINE B-FAST B/W door panel
AV4005/150
unit
T-LINE B-FAST colour door panel
AV4005/160
unit
B-FAST one family kit power
AV4005/022
supply unit
T-LINE
bracket
for
B-FAST
AV1423/011
systems
T-LINE B/W monitor
AV1423/001
T-LINE colour monitor
AV1423/002
Colour CCD outdoor camera
AK9154/001
Telecamera CCD COLORE per
AK9170/001
esterno
Power supply unit
AN7429
The system components may be installed only in systems made using the kit to which they belong.
18
KIT CONTENTS
AV4005/050 AV4005/060 AV4005/051 AV4005/061
x
x
x
x
x
x
x
x
x
x
x
x
x
x

SYSTEM OPERATION

CALL AND BUSY MANAGEMENT
The system behaves as follows when a call is received:
The entire system switches to busy for the pick-up timeout (60 seconds) when a call from a door panel is
received. The busy state is extended for other two minutes (maximum conversation time) when the handset
is picked up. The system returns to stand-by mode when the conversation is ended either by hanging up or
when the timeout is reached.
The entire system switches to busy for the pick-up timeout (60 seconds) when a monitor switches a door
panel on. The busy state is extended for other two minutes (maximum conversation time) if the handset is
picked up. The system returns to stand-by mode when the conversation is ended either by hanging up or
when the timeout is reached.
All monitor extensions switch to busy for the pick-up timeout (60 seconds) when an intercom call is
established, if there are several monitors in the same system. The intercom call can only be interrupted from
call by door panel. The busy state of the other monitors is exceed by other ten minutes (maximum intercom
conversation time) when the monitor extension is picked up. The monitors return to stand-by mode when
the conversation is ended either by hanging up or when the timeout is reached. The conversation can be
interrupted at any time by a call from a door panel.
A fl oor call will not effect the busy state of the system.
DOOR PANEL FUNCTIONS
CALL MANAGEMENT
The door panel forwards the call and switches on the camera when the call button is pressed. The door panel
switches the camera off at the end of the conversation.
LOCK MANAGEMENT
The door panel has two capacitance discharge terminals for managing the lock (AP-, AP+). The lock is released
in the following cases:
Whenever the hall button is pressed (TA, GND terminals).
When a door open command is received from a monitor according to the operating mode ('free', 'privacy')
selected by the dip switch (FUN) in the door panel.
'Privacy': the door lock will be released when the door opener button of a monitor is pressed only if a
conversation with the door panel has been established or if the handset has not been picked up after
receiving a call (or door panel auto power-on).
x
'Free': the door lock can be released by pressing a monitor door opener button also if no communication has
been established.
x
SURVEILLANCE CAMERA AUTO POWER-ON FUNCTION
x
Either one single surveillance camera can be connected directly to the door panel (terminals V, S) or up to four
surveillance cameras can be connected using the AV4005/017 camera cycle unit controlled by terminals SW and
0. In this case, remember to connect the AN7429 power supply unit to the camera cycle module.
The door panel can be automatically switched on by pressing the specifi c button on the monitor (button •).
x
The surveillance camera feed only will appear on the monitor if the button is pressed repeatedly after auto
power-on. Pick up the handset to establish an audio and video communication with the door panel unit. The
surveillance camera cyclic auto power-on function must be enabled by means of the door panel dip switch (see
x
section on programming).
x
DS90365-005
DS90365-005
19
