MAINTENANCE
SCHEDULE
Weekly
(only for FDX-PRO, FDX4
and FDX Xtreme if the
water is pumped from
a tank)
Monthly
CAUTION
• When working, the high pressure cleaner should not be too noisy and there should be no obvious
drips of water or oil underneath it. If this is the case have the machine checked by a Specialized
Technician.
Special maintenance must only be done by a Specialized Technician, complying with the following table.
Also remember to carry out the special maintenance jobs listed in the engine operating and maintenance
manual.
MAINTENANCE
SCHEDULE
After the first 10 hours
(FDX2 10/150) or 50 hours
(for all the other models)
of operation
Every 200 hours
Every 500 hours
32
• Clean the water inlet filter (45).
Unscrew the cap (51) with a 27 mm fixed jaw spanner and take the cartridge out (50),
(see Fig. 7). It is normally enough to put the cartridge under running water or blow
it with compressed air to clean it. In the most difficult cases, use a scale remover or
replace it, contacting an authorised assistance centre to buy the new cartridge.
Mount the cartridge and screw the plug back down.
• Clean the water inlet filter (23).
Turn the ring nut (62) anticlockwise until it is completely undone; take the filter
cartridge (63) out and clean it as explained above; in the case of truly stubborn dirt
change the cartridge, contacting a Specialized Technician for the right cartridge
to use; put the cartridge back in place and close the filter, turning the ring nut (62)
clockwise.
• Clean the water inlet filter (45) or (23) (refer to what has been explained previously)
(only for FDX-PRO, FDX4 and FDX Xtreme).
• Clean the detergent suction filter (40) (not for FDX2 10/150 and FDX Xtreme).
It is normally enough to put the filter under running water or blow it with
compressed air to clean it. In the most difficult cases use a scale remover or replace
it, contacting an authorised assistance centre to buy the new filter.
• Clean the nozzle.
It is normally enough to put the needle (29) supplied through the hole of the
nozzle to clean it. If the results are not good, replace the nozzle purchasing it from
an authorised assistance centre.
The professional fixed fan nozzle mounted on the nozzle holder heads (24) and (25)
and spray gun (57) can be replaced using a 14 mm box spanner (not supplied). To
replace the nozzle of head (48) contact an authorised assistance centre.
• Oil or grease the rotating or sliding parts the operator is able to reach (refer also to
the engine operating and maintenance manual).
• Check soundness of the water inlet and outlet circuits.
• Check tyre inflation pressure.
• Check clamping of the pump to the engine and the engine to the frame.
If clamping is found to be insecure do not, under any circumstances, use the
high pressure cleaner and contact a Specialized Technician.

SPECIAL MAINTENANCE

• Change pump oil.
• Check the pump's hydraulic circuit.
• Check pump and engine clamping.
• Change pump oil and gearbox oil.
• Check the pump suction/delivery valves.
• Check tightness of pump screws.
• Check the pump regulation valve.
• Check the safety devices.
JOB
JOB
