Fig.23
Secure your child in it by fastening the lap and diagonal belts (D) of the three-point-ve-
hicle-belts and locking it with an audible »click« sound. The lap belt (O) needs to lead
under both armrest near the buckle. The diagonal belt (N) goes through and under
armrest near the buckle. Check that the webbing has not become twisted and tighten
the seat belt by pulling the diagonal strap upwards.
fig. 24
Thread the diagonal belts through the seat belt hook (M) and check that all of the slack
has been removed from the seat belt
Thread the diagonal belt through the belt guide at the headrest and tighten it in the di-
rection of the retracting mechanism. Make sure that the diagonal belt lies firmly against
the child's body and is not twisted. Also check that the cover is
not impeding the movement or fit of the seat belt webbing in any way.
To release your child, simply unfasten the seat belt in the normal way.
Do not fasten the belts in any other way than described here, otherwise the child will
not be held or secured properly. Make sure that the diagonal belt is carefully positioned
and does not run too close to the child's neck. All belts must lie firmly against the child's
body without twisting. If necessary, install a height adjuster mechanism into the car to
correspond to your child's size. Do not attempt to use it without fastening in the car.
2.3. Adjusting the headrest to the child's size (fig. 6)
In order to adjust the height of the head rest to your child's size go exactly the same
procedure as described in Section 1.3.5 described for Group 1.
c -capsula.com
25

3. Fitting the car seat without backrest

Attention: Only use the booster is recommended for children from (approximaterly)
7 to 12 years, about 22 to 36 kg
fig. 25
Rotate the backrest to the horizontal position.
Then pull out the backrest from the base.
fig. 26
Place the Booster (C) firmly into position in the desired car seating position.
Then sit your child on the Booster.
The position of red belt hook (M) should be adjusted to the height of the child's shoulder.
Fasten the adult 3-point seat belt across your child. The diagonal section of the belt
must pass across the child's chest (not the neck) and go through the red belt hook (M)
on the child's shoulder.
The lap section of the belt lies firmly against the child's body so that the pelvis is firmly
engaged. The seat belt guide is marked in red.
3. Make sure that the belts lies firmly against the child's body and is not twisted and
there is no slack.
4. To clean the Booster Cushion remove the cover from moulding and follow
the instructions on the label.
