3. Keep the lever de-blocked and pull the head rest simultaneously up or down,
as your need, according to the child's size.
Relase the lever. The head rest needs to be fixed in one of the guide wholes with an
audible sound. Please check by pulling on the head rest, if it does not move anymore
without pulling the lever. The middle of the head rest needs to be exactly at the height
of the middle of the child's head to have the highest side protection effect. The dis-
tance between head rest and shoulder of the child should be 2 fingers. The headrest is
adjustable in 7 different positions.
1.4. Installing capsula MT6 into your car
®

1.4.1. Conditions for installation

capsula MT6 may be placed on all passenger seats of the vehicle that are equipped
®
with a three-point-vehicle-belt. The child seat must not be positioned on a vehicle seat,
which only has a lap belt, example given the centre back seat of cars with
three seats in the back.

1.4.2. Placing on the vehicle seat

Now put capsula MT6 into the car seat in driving direction.
®
Your child seat can only be installed forward facing using a three-point lap and
diagonal seat belt in the front or rear passenger seats of the car.
The three-point-belt of a vehicle is made of 4 parts: the lap belt (O), the diagonal belt
(N), the belt latch (P) and the belt buckle (Q).
The safest seating position for this child car seat is on the rear seat of a vehicle.
Do not use this child seat in the home. It has not been designed for home use and
should only be used in your car.
c -capsula.com
21
1.4.3. Installation and fixing (fig. 16 - 20)
fig. 16
Place the child safety seat on the vehicle's seat ensuring it is firmly pressed
against the car seat backrest.
fig. 17
Thread the car seat belt in through the seat belt route slot in the seat's plastic
backrest furthest from the car's seat belt buckle, and then out through the
other seat belt route slot and fasten it into the seat belt buckle.
fig. 18
Check the webbing of the seat belt has not become twisted or tangled and
that the lap belt goes under the armrest and the diagonal belt cover
armrest before proceeding.
Please Note at the back of the backrest, the diagonal belt is upper and go through
this hook (R).
fig. 19
Place your knee on the base of the safety seat and grip the top piece of
seatbelt webbing. Pull the webbing upwards to tighten the seat belt.
fig. 20
Finish tightening the webbing by pulling the diagonal strap upwards until
there is no slack and the seat is held firmly in place. Now you can strap your
child into the seat.
Attention:
The belts must not be twisted or blocked. The belt anchorage (U) must not be blocked
either. Also check that the cover is not impeding the movement or fit of the seat belt
webbing in any way.
To release your child seat follow the above instructions in reverse order.
Please refer to the scribbles in case of any doubt or contact your dealer, importer or
manufacturer.
