English
1. GROUP I (9 month to 4 years, about 9 to 18 kg) ................................................................. S. 18
®
18 1.2. Connecting the backrest to the booster .................................................................... S. 18
®
1.3.1. Preparation ............................................................................................................ S. 19
1.3.2. Height adjustment of the shoulder belts ............................................................. S. 19
1.3.3. Slackening the harness ......................................................................................... S. 20
1.3.4. tightening the harness .......................................................................................... S. 20
1.3.5. Adjusting the headrest to the child's size ........................................................... S. 20
®
1.4.1. Conditions for installation ..................................................................................... S. 21
1.4.2. Placing on the vehicle seat ................................................................................. S. 21
1.4.3. Installation and fixing ............................................................................................ S. 22
2. GROUP II+III (4 to 12 years, about 15 to 36 kg) .....................................................................S. 24
®
2.3. Adjusting the headrest to the child's size .................................................................... S. 25
3. Fitting the car seat without backrest .................................................................................... S. 26
4. Care instructions .......................................................................................................................S. 27
5. Important notices .....................................................................................................................S. 28
6. Some final hints ........................................................................................................................S. 29
Operating Instructions
A
Headrest
K
Harness adjuster level
B
Backrest
L
Red Button
C
Chest Pad
(adjust headrest height)
D
Harness belt
M
Belt Lock
E
Comfort Pad
(only used for 15 - 36 kg)
F
Booster
N
Diagonal belt of the
G
Seat cushion
three-point-vehicle-belt
H
Harness adjuster strap
O
Lap belt of the
I
Slot
three-point-vehicle-belt
J
Belt buckle
c
-capsula.com
17
®
®
P
Buckle latch of the
three-point-vehicle-belt
Q
Belt buckle of the
three-point-vehicle-belt
R
Diagonal belt hook
S
Seats belt route slots
T
Harness straps
U
Belt anchorage
V
Connecting Hooks
W
Holes (for Hooks)
1. GROUP I (9 month to 4 years, about 9 to 18 kg)
1.1. Using capsula
MT6 as a child car seat
®
You have purchased capsula
MT6 car seat for your child. We thank you for your trust.
®
Please note, that the optimum safety characteristics can only be achieved, if the seat
is used properly according to instructions. These instructions are important. Therefore
we ask you to ensure the correct installation of the seat in your vehicle by reading the
operating instructions carefully and retain for future reference. Please keep instructions
always with the seat for further information. Only to be assembled by adults!
Please read thoroughly before commencing installation as an incorrect installation
could be dangerous.
1.2 Connecting the backrest to the booster (fig.25) (just if non-assembled)
This child seat can be used with backrest so if backrest (B) and booster (F) are delivered
in a non-assembled way, please follow these instructions to connect both together
before using it for children in group I, II & III:
Lay down the booster on the floor and the backrest flat right behind. Then thread the
connecting hooks (V) on the bottom of the backrest into the fitting holes (W) on the
back of the booster (F) with a firm downwards motion. Now bring the backrest slowly
upright 90° to the booster. The connecting hooks should now slip into the fitting holes
with an audible sound. As a result the backrest should be well fixed to the booster in the
upright position.
It must not slip away now. Otherwise you may not have fixed it very well and using it
would be dangerous. In this case please repeat the first steps of this part of the instruction.
c
-capsula.com
English
D
GB
18
