1. GROUP I (about 9 to 18 kg Y)
1.1. Using Heyner MultiProtect Ergo as a child car seat
You have purchased Heyner MultiProtect Ergo car seat for your child. We thank you for
your trust. Please note, that the optimum safety characteristics can only be achieved, if the
seat is used properly according to instructions. Therefore we ask you to ensure the correct
installation of the seat in your vehicle by reading the operating instructions carefully. Please
keep instructions always with the seat for further information.
Only to be assembled by adults!
Connecting the backrest to the booster seat (fig.26)(just if non-assembled)
If backrest (B) and booster (C) are delivered in a non-assembled way, please follow these
instructions to connect both together before using it for children in Group I, II & III:
Lay down the booster on the floor and the backrest flat right behind. Then thread the
connecting hooks (R) on the bottom of the backrest into the fitting holes (S) on the back of
the booster with a firm downwards motion. Now bring the backrest slowly upright 90° to the
booster. The connecting hooks should now slip into the fitting holes with an audible sound.
As a result the backrest should be well fixed to the booster in the upright position. It must not
slip away now. Otherwise you may not have fixed it very well and using it would be
dangerous. In this case please repeat the first steps of this part of the instruction.

1.2. Adjusting

Heyner MultiProtect Ergo to your child's size
1.2.1. Preparation (fig.1a-c)
Heyner MultiProtect Ergo has its own belt system (D), the harness belts, which needs to be
adjusted to your child's size as follows:
1
Place Heyner MultiProtect Ergo on a normal chair and set your child in it. To ensure
optimum positioning of the belts, make sure that the shoulder belts (D1) run down from just
above the child's shoulders (fig.1c), not too high above them (fig.1b) and not too low
(fig.1a).
Don't leave your child unattended in the seat!
1.2.2. Height and length adjustment of the shoulder belts (fig.2a-c)
Height adjustment of the shoulder belts (D1):
Release the belt ends from the belt anchorage (K) at the back of the seat (fig.2a), release
the shoulder pad connector (W), pull all belt ends out of the slots (J1 or J2 or J3). Put the
belt ends through the belt slots (J1 or J2 or J3) that are appropriate to the child's size.
Finally, thread the belt ends back into the belt anchorage (K) and shoulder pad
connector (W).
To release the shoulder belts (fig.2b), push the metal belt adjuster (H), hidden by the
cover, and pull both harness belts simultaneously forward.
To shorten the shoulder belts (fig.2c), just pull the harness central belt (D3). Do not block
the shoulder belts during pulling.
Attention: It is recommended to check the belt position very regularly and to adjust it to the
size of your growing child. The belts must lie firmly against the child's body and must not be
twisted.
1.2.3. Adjusting the headrest to the child's size (fig.2d)
In order to adjust the height of the headrest (A) to your child's size, push the seat down on
the vehicles seat to keep it there. With the other hand pull the headrest forcibly up or down,
according to the child's size. The headrest needs to be fixed in one of the guide slots with an
