1.18 RGBHV / RGBS / YPbPr (BNC)

Pin No.
RGBS
1 Red
2 Green
3 Blue
4 H-Sync / C-Sync
5 V-Sync
6
1.19 OPTICAL (available on
Pin No.
1 OPTICAL Clock
2 OPTICAL Blue
3 OPTICAL Green
4 OPTICAL Red

1.20 GPIO

Pin No.
1 PIP Swap
2 PIP, PBP, PB2 Select
3 Record Indicator
4 Gnd
Assignment
Y Pb Pr
Pr
Y
Pb
No Connection
No Connection
Ground
VP47XXF Monitors
Assignment
Assignment
E-33
6
R/Pr G/Y B/Pb
1 2 3
Only)
1 2 3
E
C-SYNC/HS VS
4 5
4
