1.7.2

Rear Panel

❶
AC / DC IN Jack
❷
ON / OFF Switch
❸
OPTICAL IN (OPTIONAL) Connector
(Available only on VP47XXF
❹
DVI IN Connector
➎
DVI OUT Connector
➏
VGA IN Connector
❼
GPIO Connector
❽
RS232C Connector
➒
HD SDI IN Connector
➓
HD SDI OUT Connector
RED / Pr Connector
11
12
11 14
13
❹ ❺
Models)
18
15
❻
GREEN / Y Connector
12
BLUE / Pb Connector
13
C-SYNC / H-SYNC Connector
14
VS (V-SYNC) Connector
15
S-VIDEO / Y Connector
16
S-VIDEO / C Connector
17
Composite (C) VIDEO Connector
18
