1.9

On-Screen Display Menus

E
1.9.1

DSUB ANALOG/RGBS Input Source

Adjust Menu
❶
BRIGHTNESS
brightness (Range: 0~100).
❷
CONTRAST
(Range: 0~100).
❸
SATURATION - Changes the tone of the color
(Range: 0~100).
❹
COLOR - Changes the richness of the color
(Range: Green 0~50, Red 0~50).
➎
CLOCK
frequency (Range: 0~100).
➏
PHASE
(Range: 0~100).
❼
BACK LIGHT
light dimming level (Range: 0~100).
❽
AUTO ADJUST
screen on the D-SUB Analog signal.
Color Temp Menu
❶
MODE
- Change the color temperature mode:
6500K, 5600K, USER. When USER is selected, a
sub-menu displays allowing the user to adjust the
RED, GREEN or BLUE balance.
❷
RED
- Red balance- Only works with USER mode
(Range: 0~100).
❸
GREEN
mode (Range: 0~100).
❹
BLUE
- Blue balance- Only works with USER
mode (Range: 0~100).
- Increase or decrease the
- Increase or decrease the contrast
- Increase or decrease the sampling
- Increase or decrease the phase level
- Increase or decrease the back
- Fit to the most appropriate
- Green balance- Only works with USER
E-10
