1.15 S-Video (BNC)

E
Pin No.
1
2
3

1.16 RS232C (D-SUB 9 Pin)

Pin No.
1
2
3
4
5
6
7
8
9

1.17 SDI (BNC)

Pin No.
1
2
3
Assignment
S_VIDEO / Y (Luma)
S_VIDEO / C (Chroma)
Ground
Assignment
No Connection
TXD
RXD
No Connection
Ground
No Connection
No Connection
No Connection
No Connection
Assignment
SDI IN
SDI OUT
Ground
E-32
3
1
1 5
6 9
3
1
2
2
