1.10 OSD System Overview

E
MENUS
BRIGHTNESS
CONTRAST
PHASE
CLOCK

BACKLIGHT

AUTO ADJUST
SHARPNESS
SATURATION
COLOR
COLOR TEMP
6500K
COLOR TEMP
5600K
COLOR TEMP USER
H POSITION
FUNCTION DESCRIPTION
Adjust the image brightness.
Setting the brightness too high will cause the image to bloom or flare, too
low will decrease the visible light
Adjust the image contrast.
Setting the Contrast too high or too low will causes loss of some greyscales.
Adjust the phase level.
Do not adjust manually - fine adjustment will occur automatically during
auto adjustment. When the phase value is wrong, the image may have
interference from "noise".
Adjust the sampling frequency.
Do not adjust manually - fine adjustment will occur automatically during
auto adjustment. When the frequency value is wrong, the horizontal image
may be the wrong size or have interference from "noise".
Adjust the backlight dimming level. Setting the backlight too low will
cause a dark image and too high will decrease the backlight lifetime.
Fit to the most appropriate screen on the D-SUB Analog signal.
Adjusts the sharpness of the video image
Changes the tone of the color
Change the tone richness of the color
Default 6500K color setting
Default 5600K color setting
Default 6500K color setting. When USER is selected, Red, Green and
Blue values are changeable by the user.
Adjusts the Horizontal (left / right) position of the image. It will return to
the default state when executing AUTO ADJUST OR RESET SETTINGS
E-24
