VessRAID 1000i Series Quick Start Guide
3. Type the new IP Address.
4. Follow the same procedure to specify the Subnet Mask, Gateway IP
Address and DNS Server IP Address.
If you do not have a DNS server, skip the DNS Server IP address.
5. Press Ctrl-A to save these settings and move to the RAID configuration
screen.
Making Automatic IP Settings
To make Management Port and iSCSI Port settings automatically:
1. Press the arrow keys to highlight DHCP .
2. Press the spacebar to toggle to Enable.
3. Press Ctrl-A to save these settings and move to the RAID configuration
screen.
Configuring the RAID
You can configure your RAID arrays and logical drives using the CLU at this time.
However, those actions are described in Task 8 using WebPAM PROe. The
suggested action is to highlight Skip the Step and Finish and press Enter.
Viewing IP Address and Settings
To view the current IP address and network settings when using DHCP:
1. In the CLU Main Menu, highlight Network Management and press Enter.
2. Highlight the Management Port or iSCSI Port you want and press Enter.
Highlight DHCP and press the spacebar to toggle to Disable .
3.
The current Management or iSCSI Port settings are displayed.
4. Press the spacebar to toggle DHCP back to Enable .
5. Press Ctrl-A to save these settings and move to the RAID configuration
screen.
Exiting the CLU
In the CLU Main Menu, highlight Return to CLI and press Enter.
This completes the Management Port setup.
Go to "Task 9: Creating Disk Arrays with WebPAM PROe" on page 27.
Setting up with the LCD
The LCD Panel displays the current IP address during normal operation. If you
did not install the LCD Panel, see "Task 2: Installing the LCD Panel (Optional)" on
page 5. The LCD does not have a date and time function.
