VessRAID 1000i Series Quick Start Guide
Figure 9. VessRAID 1730i and 1830i drive slot numbering
Figure 10.VessRAID 1720i and 1820i drive slot numbering
Install all of the drive carriers into the VessRAID enclosure to ensure proper
airflow, even if you do not populate all the carriers with disk drives.
