1. General description

The UPE Series 2000 is a complete range of circula-
tor pumps with integrated differential pressure con-
trol enabling adjustment of pump performance to the
actual system requirements. In many systems, this
will mean a considerable reduction in power con-
sumption, prevent noise from thermostatic valves
and similar fittings, and improve the control of the
system.
4
The desired head can be set on the pump control
panel.
Page
These instructions apply to the pump types UPE
4
50-120, UPE 65-120, UPE 80-120 and UPE 100-60.
4
The pump offers the following functions:
4
• Proportional-pressure control (factory setting).
5
The head is changed in accordance with the flow
5
demand. The desired head can be set on the
5
pump control panel.
5
• Constant-pressure control. A constant head is
5
maintained, irrespective of flow demand. The de-
5
sired head can be set on the pump control panel.
5
• Constant curve duty. The pump runs at a con-
6
stant speed on or between the max. and min.
6
curves.
7
• Temperature influence. The head varies depend-
8
ing on the liquid temperature.
8
• External fault signal via a potential-free output.
8
• External analog control of head or speed from
8
an external 0-10 V signal transmitter.
10
10 • External forced control via inputs for:
10 - Start/stop,
11 - Max. curve,
11 - Min. curve (night-time duty).
12
• Bus communication. As the UPE Series 2000 in-
12
corporates an input for bus communication, the
12
pump can be controlled and monitored by a
12
GRUNDFOS Pump Management System 2000 or
13
a building management system.
13
• Remote control. The pump can be operated by
13
means of the GRUNDFOS wireless remote control
13
R100.
16
17

2. Applications

17
18
The UPE Series 2000 is designed for circulating liq-
19
uids in heating systems. The pumps can also be
20
used in domestic hot-water systems.
21
UPE Series 2000 is suitable for:
21
• systems with a constant flow where it is desirable
21
to optimize the setting of the pump duty point and
22
• systems with variable flow-pipe temperatures.

2.1 Pumped liquids

Thin, clean, non-aggressive and non-explosive liq-
uids, not containing solid particles, fibres or mineral
oil.
In heating systems, the water should meet the re-
quirements of accepted standards on water quality in
heating systems, e.g. the German standard VDI
2035.
In domestic hot-water systems, it is advisable to
use UPE pumps only for water with a degree of hard-
ness lower than approx. 14°dH.
For water with a higher degree of hardness a direct-
coupled TPE pump is recommended.
The pump must not be used for the trans-
fer of inflammable liquids such as diesel
oil, petrol or similar liquids.
