Operational Limits

Tab. 10
INPUT VOLTAGE (V)
< 180
180 – 264
> 264

Status LED

Tab. 11
LED STATUS
Off
Green blinking
Green
Red
Red blinking
Orange + Off
Orange blinking
When you switch the controller on an electronic self-test is performed, during
NOTE
such phase you'll see the led Orange for 1 sec. And turned off for two other
seconds. Immediately after the first phase the controller per-form a specific test
on the pump rotor in order to be sure that it isn't locked.
MS40+ Single Stage Rotary Vane Pumps User Manual / 87-901-008-01
RS 232/RS 485 Communication Description
CONTROLLER STATUS
Power fail
Operative
Power fail
CONTROLLER STATUS
Stop
Ramp – Autotuning
Normal Operation
Fail
Oil level fail
Reset + selftest
Maintenance required
