Technical Information
RS 232/RS 485 Communication Description
WIN
TYPE
R/W
206
N
R
207
N
R
211
N
R
216
N
R
222
N
R
225
N
R
233
N
R
300
N
R
301
N
R
302
N
R
305
N
R
306
N
R
307
N
R
319
A
RW
320
A
RW
321
A
RW
322
A
RW
323
A
RW
358
N
RW
362
N
R
364
N
R
365
N
R
382
N
R
384
N
R
400
A
R
402
A
R
406
A
R
407
A
R
503
N
RW
504
L
RW
80/90
MS40+ Single Stage Rotary Vane Pumps User Manual / 87-901-008-01
DESCRIPTION
ERROR CODE: Bit 7: Motor blocked; Bit 6: shortcircuit; Bit 5:
Undervoltage/Overvoltage; Bit 4:Motor overtemp; Bit 3: Verify line; Bit 2:
Controller overtemp; Bit 1: Bus Undervoltage; Bit 0: overcurrent
OUTPUT FREQUENCY [rpm]
JGBT TEMPERATURE [°C]
CONTROLLER TEMPERATURE [°C]
POWER SUPPLY TEMPERATURE [°C]
OIL LEVEL (0=level ok; Bit 0: underlevel; Bit 1: maintenance)
ROTATIONAL FREQUENCY [rpm]
CYCLE TIME [min]
CYCLE NUMBER
PUMP LIFE [h]
TIME WITH OIL UNDER LEVEL [min]
TIME WITH DIRTY FILTER [min]
TIME CONTROLLER STAND BY
CONTROLLER MODEL NUMBER
PUMP MODEL NUMBER
PUMP SPECIAL MODEL NUMBER
PUMP SERIAL NUMBER
CONTROLLER SERIAL NUMBER
MAINTENACE TIMER [hours]
LAST HOUR TEMPERATURE AVERAGE [°C]
LAST HOUR AVERAGE POWER [W]
LAST HOUR AVERAGE FREQUENCY [Hz]
LAST HOUR AVERAGE TEMPERATURE [°C]
AVERAGE POWER [W]
PROGRAM LISTING CRC
PARAMETER LISTING CRC
PROGRAM LISTING CODE & REVISION
PARAMETER LISTING CODE & REVISION
RS485 SERIAL ADDRESS SETTING [0-31]
SERIAL TYPE SELECT (0=RS232; 1=RS485)
