1 320 Electric heater stage 1
1 321 Operating-hour meter for electric heater stage 1.
1 322 Electric heater stage 2
1 323 Operating-hour meter for electric heater stage 2.
1 330 Fan control state
1 331 Fan operating-hour meter
1 350 Indication of the critical faults
1 351 Operating-hour meter indicating the critical faults
1 352 Indication of the non-critical faults
1 353 Operating-hour meter indicating the non-critical faults
1 360 Fan on request
1 361 Temperature setpoint shift request
1 362 Warm-up
1 363 Activation time delay for the compressor stages
1 365 CCU CONTROLLER software version number
1 570 SO order number
1 571 OF number

6.2 Humidifier parameters (visible if P10=2)

6.2.1 Settings (sub-menu 9.1)
Access
No.
level
3 900 Maximum production
3 901 Off delay time
Water conductivity
3 902 (0 = automatic measurement > 0 =
forced conductivity)
3 903 Conductivity pre-alarm threshold
3 904 Conductivity alarm threshold
Foam detection threshold control
(0 = foam detection excluded
3 905
1 = max. foam detection sensitivity;
100 = min. foam detection sensitivity)
Internal conductivity control of the
cylinder on warm-up as compared
3 906
to the nominal (less than 100%:
conductivity increases)
STATE OF THE ELECTRIC HEATER CONTROLS
STATE OF THE FAN CONTROLS
STATE OF THE FAULT SUMMARY CONTROLS
STATE OF THE FAN CONTROLS
TIME DELAY COUNTDOWN
Description
20 to 100%
0 s to 120 s
0 to 125 µS/cm
0 to 2000 µS/cm
0 to 2000 µS/cm
0 to 100%
50 to 200%
EN - 18
VERSION NUMBER
ORDER NUMBER
Setting
Off/On P16 = 2
h P16 = 2
Off/On P16 = 2 or 4
h P16 = 2 or 4
Off/On
h
Off/On
h
Off/On
h
Off/On P01 = 2
Off/On P31 = 2 or P32 = 2
mins
mins P17 = 3 or 4
By default Display condition
100 % P10 = 2
0 s P10 = 2
0 µS/cm P10 = 2
1500 µS/cm P10 = 2
2000 µS/cm P10 = 2
50 % P10 = 2
100 % P10 = 2
