Carrier CCU Controller Bedienungsanleitung Seite 51

Access
No. Description
level
2 1 On control
Number of speeds
3 2 or variation of air
flow rate
3 3 Machine model
3 5 FMA control
Limitation via
3 6 the supply air
temperature
3 7 Cooling control
3 8 Heating control
Dehumidification
3 9
control
Humidification
3 10
control
3 11 Free cooling control
Electric heater
3 16
control
3 18 Humidifier type
3 19 Type of water coil
CONFIGURATION OF THE FANS
1: Outer contact (the push button on the console acts as a forced stop)
2: Internal timer (the push button on the console acts as priority forced stop and the
outer contact as forced start)
1: One speed
10: Variation of the rotation speed with increase of the speed
via an increase in cooling control.
11: Variation of the rotation speed with increase of the speed
via an increase in heating control.
12: Variation of the rotation speed via cooling and heating control.
13: Variation of the rotation speed with decrease of the speed via an
increase in dehumidification control.
14: Manual variation of the fan rotation speed.
15: Variation of the rotation speed with pressure increase on the raised floor.
16: Variation of the rotation speed depending on the temperature difference (return/
supply air)
1: 50CJ configuration
2: 50CO configuration
0: On/off or gradual 0-10 V
1: 1 MODBUS gradual FMA
2: 2 MODBUS gradual FMA
3: 3 MODBUS gradual FMA
CONTROL SELECTION
0: No limitation
1: With limitation
(Low limit affecting cooling control, high limit affecting heating control)
0: No cooling control
1: One chilled water coil
0: No heating control
1: One hot water coil
2: One electric heater
3: Electric heater or hot water coil via contact
0: No dehumidification control
1: One chilled water coil
0: No humidification control
2: Progressive MODBUS
0 = Without
1 = With
CONFIGURATION OF THE EXCHANGERS
1: One on/off output (one stage)
2: Two on/off outputs (three stages)
3: One progressive stage
4: One progressive stage and one on/off stage
1: 3 kg/h 230 V
2: 3 kg/h 400 V
3: 8 kg/h 400 V
4: 15 kg/h 400 V
1: One mixed coil
(cooling/heating operation via contact)
2: Two self-contained coils
(one cooling coil, one heating coil)
Setting
EN - 13
Display
By default
condition
1
P05 = 0
P03 = 2 and P07 > 0
P03 = 2 and P08 > 0
P03 = 2 P07 > 0 and
P08 > 0
14
P03 = 2 P09 > 0
P04 = 1
P04 = 1
1
0 P04 = 1
P11 ≠ 0
0
0
0
P04 = 1
0
0
P04 = 1
0
P07 > 0
1 P08 = 2 or 3
1 P10 = 2
P04 = 1 and P07 = 1
2 and P08 = 1 and
P09 = 0
EN
