9 .4 Cable ties

Designation
Article number
Minimum binding force
Material
Quality
Color
Operating temperature
briefly to
Approvals/standards
Flammability
Weathering
Resistance to ageing
Chemicals
* Halogen-free as per prohibitions of the GADSL list and notification obligations of the SVHC list
Automation Instructions CPK • 10-2015 •106-29009
T18RA50 PA66HS NA 2000
T18RA3500 PA66HS NA 3500
120-40019
120-50009
80 N
Comparable cable tie: T18R
Polyamide 6.6
Heat-stabilized
Natural (NA)
Colored cable ties available on request
–40 °C to +105 °C
+145 °C (500 h)
SAE AS23190 (MIL MS 3367) - MS3367-42
HellermannTyton UL file No.: E65344
UL94 V2
better than 100 mm/min.
Good weather-resistance under
normal climate conditions
No discernible ageing in conditions
of typical use in interiors.
Very good resistance to oils, greases, lubricants, aliphatic and aromatic hydrocarbons and conventional motor-vehicle
fuels. Resistant to many organic substances, including for example ketones, ester, halogenated compounds
Not resistant to strong mineral acids and/or oxidising chemicals, especially at high temperatures
*
HF
RoHS
T18RA50 PA66HSW BK 2000
T18RA3500 PA66HSW BK 3500
120-40020
120-50010
UV-stabilized
Heat-stabilized
Black (BK)
–40 °C to +105 °C
+145 °C (500 h)
UL94 V2
better than 100 mm/min.
The effects caused by exposure to
ultraviolet light are considerably
reduced by the addition of carbon.
The addition of a stabilizer prevents
surface oxidation.
Even with strong sunlight no
significant loss of tensile strength is
discernible.
Appendix
T18RA3500 PA46 NA 3500
120-46009
Polyamide 4.6
High-temperature-resistant
Natural (NA)
–40 °C to +150 °C
+195 °C (500 h)
UL94 V2
Good weather-resistance under
normal climate conditions
No discernible ageing in conditions
of typical use in interiors.
LFH
RoHS
35
