f Slacken screws .
2
f Lift left housing cover
1
toward the rear and remove.
f Turn tool
over and carefully lay it open side down on
3
the soft work surface.
5
4
f Slacken screws .
4
f Lift housing cover
slightly at the front, ease it toward
5
the rear and remove.
f Turn the tool over and carefully lay it open side down on
the soft work surface.
f Flip waste box down to open.
8
f Slacken screw
.
6
f Ease handle
to the rear and work it down to remove.
7
Automation Instructions CPK • 10-2015 •106-29009
slightly at the front, ease it

5 .3 .2 Inserting the robot adapter CPK

f Insert robot adapter CPK
and slide it forward.
f Secure the robot adapter CPK with screw
f Install the housing covers of the tool on both sides and
tighten the screws to secure.
f Install the tool with the robot adapter CPK and connect
them to the power pack with control box.
f Make sure that all the wiring is free of kinks.

5 .3 .3 Disposing of waste material

f Ensure suitable disposal of waste material so that
even when the tool is at an extreme angle the cut
offs can drop out of the tool.
6
7
8
Installation
6
into the groove in the tool
9
.
6
9
