Construction Specifications
Power factor range of the load applied
No. of output phases
AC-AC conversion efficiency with
linear load P.F. 1 and charged
batteries
50% load
75% load
100% load
Output features: battery operation
Nominal output voltage
Output frequency
Nominal output power
Active output power with linear or
non-linear load, P.F. 0,7
Operating power with switching
load
Total harmonic distortion of
output voltage
Overload capacity
Admissible power factor range of
the load applied
DC-AC conversion efficiency with
linear load P.F. 1
at 50% of load
at 75% of load
at 100% of load
HF TOP LINE HF TOP LINE HF TOP LINE
910 920 930
1000 VA 2000 VA 3000 VA
700 W 1400 W 2100 W
1400VA 2800VA 4200VA
19
HF TOP LINE HF TOP LINE HF TOP LINE
940 940/2 950/2
from 0.7 to 1
single-phase
80%
84%
90%
230V ±1%
50Hz / 60Hz ±1%
4000 VA 4000 VA 5000 VA
2800 W 2800 W 3500 W
5600VA 5600VA 7000VA
< 1%
160% for 15 seconds
from 0.7 to 1
82%
84%
83%
HF TOP LINE HF TOP LINE HF TOP LINE
960/2 970/2 980/2
6000 VA 7000 VA 8000 VA
4200 W 4900 W 5600 W
8400VA 9800VA 11200VA
