Construction Specifications
Input features
Nominal input voltage
Input voltage range
Nominal input frequency
Nominal input current
Maximum input current
Input current distortion
Input power factor
Spike current
No. input phases
Line fuse
Output wave form
Mains operation
Battery operation
Operating type
Output features: mains operation
Nominal output voltage
Nominal output frequency
Output current with linear load, power
factor 0.7
Crest factor
Nominal output power
Active output power with linear or non-
linear load P.F. 0.7
Operating power with switching load
Total harmonic distortion of
output voltage with linear load
Total harmonic distortion of
output voltage with non-linear
load P.F. 0.7
Overload capacity
HF TOP LINE HF TOP LINE HF TOP LINE
910 920 930
from 184V to 264V with nominal load - from 110 to 264 V at 50% of nominal load
50Hz or 60Hz ±2%, programmable by user
3,7A rms 7,1A rms 10,6A rms 14,2A rms 14,2A rms 17,9A rms 21,5A rms
4,6A rms 8,9A rms 13,3A rms 17,8A rms 17,8A r
20A FF
No-break, on-line UPS with direct neutral and dual conversion.
4,3A rms 8,6A rms 13,0A rms 17,3A rms 17,3A rms 21,8A rms 26,1A rms 30,4A rms 34,8A rms
1000 VA 2000 VA 3000 VA 4000 VA 4000 VA 5000 VA 6000 VA 7000 VA 8000 VA
700 W 1400 W 2100 W
1400 VA 2800 VA 4200 VA 5600 VA 5600 VA 7000 VA 8400 VA 9800 VA 11200 VA
300% for 1 second without by-pass intervention
200% for 5 seconds without by-pass intervention
150% for 30 seconds without by-pass intervention
18
HF TOP LINE HF TOP LINE HF TOP LINE
940 940/2 950/2
230 V
ms 22,2A rms 26,6A rms 31,1A rms 35,6A rms
<10%
>0,99 at 80% of normal load
100% of nominal current
single-phase
sinusoidal
sinusoidal
230 V ±1%
50Hz / 60Hz synchronized
3,5
2800 W 2800 W 3500 W
<0.5%
< 1%
HF TOP LINE HF TOP LINE HF TOP LINE
960/2 970/2 980/2
25A rms 28,5A rms
40A FF
4200 W 4900 W
5600 W
