Danfoss AK-CC 450 Instructions Seite 18

Continued
Service
Temperature measured with S5 sensor
Status on DI1 input. on/1=closed
Actual defrost time (minutes)
Temperature measured with S3 sensor
Status on night operation (on or off ) 1=on
Temperature measured with S4 sensor
Thermostat temperature
Run time of thermostat (cooling time) in minutes
Temperature measured with S6 sensor
(product temperature)
Status on DI2 output. on/1=closed
Temperature shown on display
Measured temperature for alarm thermostat
Status on relay for cooling
Status on relay for fan
Status on relay for defrost
Status on relay for railheat
Status on relay for alarm
Status on relay for light
Status on relay for valve in suction line
Status on relay for compressor 2
Temperature measured with S5B sensor
Temperature measured with S3B sensor
Temperature measured with S6B sensor
Status on relay for hot gas- / drain valve
Status on relay for heating element in drip tray
Status on relay for night blinds
B
Status on relay for defrost
Status on relay for heat function
Readout of the actual rail heat effect
1: Thermostat 1 operating, 2: Thermostat 2 operating
Status on high voltage input DI3
Readout of thermostats actual cut in value
Readout of thermostats actual cut out value
Readout the actual rail heat effect in %
*) Can only be set when regulation is stopped (r12=0)
**) Can be controlled manually, but only when r12=-1
***) With access code 2 the access to these menues will be limited
Forced control
If you need to force-control an output, you should set r12 to -1 (manual mode). You should then select
the relevant relay function, e.g. u58. Go to the function by pressing the middle button. Select On.
Factory settings are indicated for standard units. Other code numbers have customized settings.
18
Code
u09
u10
u11
u12
u13
u16
u17
u18
u36
u37
u56
u57
** u58
** u59
** u60
** u61
** u62
** u63
** u64
** u67
u75
u76
u79
** u80
** u81
** u82
** u83
** u84
u85
u86
u87
u90
u91
U02
