tRouBlEShootiNg

Problem
Module is not
recognized when
connected to the
CPAP.
Card not
recognized when
inserted into the
module card slot.
Card error.
Settings error.
Setup required.
Oximeter data
(SpO 2 and PR) not
displayed.
A-DV5M-1
Probable Cause
1. The CPAP is not
connected to a power
source.
2. Module is not fully
attached to the CPAP.
1. Card not oriented
properly.
2. Card not fully inserted in
the module card slot.
3. Module is not fully
attached to the CPAP.
1. Wrong card type.
2. Card removed during
data transfer.
3. Card corrupt or faulty.
1. Card removed during
data transfer.
2. Card corrupt or faulty.
1. Module not set up
properly.
1. Oximeter not properly
connected to the
SmartLink module.
2. Oximeter probe not
properly attached to user.
Remedy
1. Connect the CPAP to an appropriate power source
and verify that the module is recognized.
2. Remove the module from the CPAP, realign the
primary data connector with the circular DIN
connector of CPAP, and press firmly until the module
is locked into position. Be sure there is not a gap
between the module and the CPAP.
1. Refer to the symbol on the top of the module or
Figure 4 in this guide for proper card orientation.
2. Press the card fully into the card slot until the card
clicks into position.
3. Remove the module from the CPAP, realign the
primary data connector with the circular DIN
connector of CPAP, and press firmly until the module
is locked into position. Be sure there is not a gap
between the module and the CPAP.
1. Only use a card supplied by your provider. The card
must be an SD card with FAT16 format.
2. Card must not be removed during data transfer. Data
transfer interruption may corrupt the card and
prevent the card from working correctly. Reinsert
card and allow data transfer to continue until
completed.
3. Return card to provider for replacement.
1. Card must not be removed during data transfer. Data
transfer interruption may corrupt the card and
prevent the card from working correctly. Reinsert
card and allow data transfer to continue until
completed. If this error is not corrected, contact
provider for resolution.
2. Return card to provider for replacement. If this error
is not corrected, contact provider for resolution.
1. Notify provider of the situation and follow provider
instructions.
1. Verify connection between the oximeter connector
and module oximeter connection port.
2. Reference the operating instructions that came with
oximeter.
EN - 9
