Features And Specifications; Identification Of Parts - Comet 8 Bedienungsanleitung

Mechanical
connecTion
Power consumption at max.
rotation speed and pressure
Max. pump rotation speed
Min. pump rotation speed
puMp oil
hydraulic connecTion
Max. supply water temperature
Min. supply water temperature
Min. suction difference in height
Max. supply water pressure
perforMance
Flow rate at maximum pressure
Flow rate at 0 bar
Maximum pressure
Sound pressure level
WeiGhT
The features and specifications are provided for reference only. The Manufacturer reserves the right to alter products at
Refer to Fig.1 and Fig.2 at the beginning of the operation and maintenance manual
1. Pressure accumulator
2. Pump head
3. Suction coupling
4. Delivery coupling
5. Pump case
6. By-pass/pressure control lever
7. Oil cap
8. By-pass coupling
9. Control valve
10. Suction valve cap
11. Delivery valve cap
12. Pressure gauge (25 only)
13. Reduction unit for special electric motor
pressure limiting/control valve
This valve controls the operating pressure and enables the pumped liquid to return to the bypass pipe,
preventing the risk of dangerous pressures when the delivery is closed or should you try to set the pressure
above the maximum allowed.
20

feATUReS ANd SPecIfIcATIONS

8
0,20 kW - 0,27 CV
1450 / 1750 RPM
1000 RPM
AGIP BLASIA S 150 (ISO-L-CKD)
6,9 l/min - 1,8 US gpm 10,7 l/min - 2,8 US gpm
7,7 l/min - 2,1US gpm 11,9 l/min - 3,1 US gpm
1,5 MPa
15 bar - 217 psi
62 dB(A)
1,6 kg - 3,5 lb
any time.

IdeNTIfIcATION Of PARTS

14. Reduction unit for special two-stroke combustion engine
15. Reduction unit for four-stroke combustion engine with
16. Reduction unit for four-stroke combustion engine with
17. Cylinder shaft Ø 17 for pulley
18. Cardan shaft 1"3/8
19. Flange and shaft for MEC 71 standard electric motor
20. Delivery cap
21. Identification plate
22. Pulley
23. Flange and shaft for NEMA 56 5/8" electric motor
24. Cylinder shaft Ø 17
SAfeTY devIceS
18
0,38 kW - 0,52 CV
40 °C - 104 °F
5 °C - 41 °F
1 m - 8,2 ft
0 bar - 0 psi
3/4" or 5/8" shaft and SAE J609a flange
5/8" shaft and SAE J609a flange
20/20
0,88 kW - 1,2 CV 1,1 kW - 1,5 CV
650 RPM
400 RPM
SAE 20W/40
18,5 l/min - 4,9 US gpm
23 l/min - 6,1 US gpm
2,0 MPa 2,5 MPa
20 bar - 290 psi 25 bar - 363 psi
64 dB(A) 65 dB(A)
4,7 kg - 10,4 lb
25
