Teileliste - CARDIOSTRONG EX70 Montage- Und Bedienungsanleitung

8.3

Teileliste

Nr. Bezeichnung (ENG)
1 Main Frame
2 Tension Bracket
3 Eye Bolt
5 Bearing (6000)
6 Pulley (120-42mm)
7 Belt (1092J6)
8 Spacer (10x14x32mm)
9 Crank
10 C-Ring
11 Bearing (6004)
12 Sensor Stand
13 Crank Axle
14 Magnet
15 Cable
16 Pulley (235mm)
17 Motor
18 Flywheel
19 Belt (1059J8)
20 Crank Cover
21 Left Cover
22 Accessory Tray
23 Right Cover
24 EndCap
25 Rear Stabilizer
26 Fixed Plate for Leveler
27 Leveler
42
Anz. Nr. Bezeichnung (ENG)
1 27 Leveler
4 28 Front Stabilizer
4 29 Transportation Wheel
2 30 Support Tube
1 31 Console
1 32 Fixed Handlebar
1 33 Pulse Sensor Top Housing w/ Wire
2 34 Pulse Sensor Bottom Housing
2 35 Tube Cap
6 36 Right Swing Arm
1 37 Bearing (6201)
1 38 Spacer (8x14x40mm) for Telesco-
ping Bar
1 39 Spacer (6x8x22mm)
1 40 Crank Linkage
1 41 Spacer (8x14x28mm) for Crank
Linkage
1 42 Handheld Plug
1 43 Foam Grip for Upper Handlebar
1 44 Left Upper Handlebar
2 45 Right Upper Handlebar
1 46 Bearing (6905)
1 47 Left Pivoting Arm
1 48 Right Pivoting Arm
4 49 Stride Length Adjustment Plate
1 50 Telescoping Bar
4 51 Connection Plug (60x38)
4 52 Left Adjustment Tube
Anz.
4
1
2
1
1
1
2
2
4
1
16
4
2
2
4
2
2
1
1
4
1
1
2
2
4
1
EX70
