Teileliste - CARDIOSTRONG CST-MEP Montage- Und Bedienungsanleitung

6.2

Teileliste

Nr. Bezeichnung (ENG)
1 Crank arm assembly (R)
2 Crank arm assembly (L)
3 PU wheel
4 Magnet arm
5 Flying wheel set
6 Main frame
7 Crank axle fixing plate
8 Pulley wheel set
9 Spindle for PU wheel
10 Bolt for Magnet arm
11 Spring
12 Washer
13 Decorative cover
14 Decorative cover
15 "Pedal cover right side upper"
16 "Pedal cover right side lower"
17 Pedal cover left side upper
18 Pedal cover left side lower
19 Cushion
20 TPU cushion
21 Shell (L)
Anz. Nr. Bezeichnung (ENG)
1 22 shell (R)
1 23 Plastic plug
2 24 LCD Display
1 25 Resistance Knob
1 26 Driving belt
1 27 EVA Mat
2 28 Square sensor
1 29 Hex nut M5
2 30 Hex nut M6
1
31 Hex nut M10x1.0
1
32 Hex socket screw M5x30
2
33 screw M6x10
2
34 screw M6x40
1
35 Bearing 61902ZZ
1
36 Self-tapping screw ST4.2x20
1
37 Self-tapping screw ST4.2x10
1
38 Self-tapping screw ST4.2x15
1
39 Flat washer 5.3 * 10.0 * T1
2
40 C-clip 17.0xΦ15.7xT1
2
41 C-clip 15.0xΦ13.8xT1
1
42 wrench S5
