CARDIOSTRONG EX70 Montage- Und Bedienungsanleitung Seite 43

Nr. Bezeichnung (ENG)
53 Right Adjustment Tube
54 Pull Pin
55 Pedal
56 Oval Plug (30x60)
57 Square Plug (20x40)
58 Support Arm
59 Sensor Wire
60 Upper Connection Wire
61 Middle Adaptor Connection Wire
62 Lower Adaptor Connection Wire
63 Adaptor
64 Connection Wire to Console
65 Lock Washer (M8)
66 Washer (8×16×2.0t)
67 Washer (8×30×2.0t)
68 Washer (10×23×2.0t)
69 Washer (21×30×0.5t)
70 Washer (21×30×1.0t)
71 Tube Connector Nut
72 Flange Nut (M10xp1.25)
73 Nylon Nut (M6xp1.0)
74 Thin Nylon Nut (M8xp1.25)
75 Nylon Nut (M8×p1.25)
76 Nylon Nut (M10×p1.5)
77 Bolt (M6×p1.0×12mm)
78 Bolt (L=30mm)
79 Screw (M4×20mm)
Anz. Nr. Bezeichnung (ENG)
1 80 Screw (M5×20mm)
2 81 Screw (M3×p0.5×16mm)
4 82 Screw (M5×p0.8×15mm)
8 83 Bolt (M6×p1.0×12mm)
2 84 Bolt (M8×p1.25×16mm)
1 85 Bolt (M8×p1.25×20mm)
1 86 Bolt (M8×p1.25×30mm)
1 87 Bolt (M8×p1.25×16mm)
1 88 Bolt (M8×p1.25×65mm)
1 89 Bolt (M8×p1.25×75mm)
1 91 Bolt (M8×p1.25×15mm)
20 92 Bolt (M10×p1.5×85mm)
20 93 Washer (26×34×1.0t)
4 94 Bolt (M8×p1.25×25mm)
2 95 Bolt (M8×p1.25×45mm)
1 96 Screw (M5×p0.8×15mm)
4 97 Axle Cap
2 98 Pulse Connection Wire to
Console
4 99 Left Swing Arm
4 100 Pedal Wheel Bearing Adapter
12
4
5
2
2
4
Anz.
11
4
4
4
2
3
10
13
4
4
4
1
2
4
4
2
16
1
1
2
43
