Teileliste - CARDIOSTRONG CST-EX60-TOUCH Montage- Und Bedienungsanleitung

8.2

Teileliste

Nr. Bezeichnung (ENG)
A MAIN FRAME
A1 SENSOR WIRE 1000mm
A5 SENSOR WIRE HOUSING
A6 SENSOR WIRE 900mm
A7 SCREW
A8 PULLEY
A9 MANGET Φ15*7
A10 AXLE
A11 SCREW
A12 NUT
A13 NUT
A14 BEARING
A15 PRESSING PLARE
A16 SCREW
A17 BEARING HOUSING
A18 BEARING
A19 WASHER
A20 SCREW
A21 SPRING
A22 NUT
A23 SCREW
A24 TURNING PLATE
A25 PIPE
A26 NUT
A27 DECORATION COVER
A28 DC WIRE
A29 BELT
A30 MAGNETIC FLYWHEEL
A31 AXLE
A32 BEARING
A33 WASHER
A34 BUSH
32
Anz. Bezeichnung (ENG)
Nr.
1 A35 WASHER
1 A36 NUT
1 A37 PLATE COVER
1 A38 SCREW
2 A39 MAGNETIC HOUSING
1 A40 SCREW
1 A41 NUT
1 A42 MAIN CHAIN COVER ( L )
4 A43 MAIN CHAIN COVER ( R )
1 A44 SCREW
4 A45 SCREW
2 A46 WASHER
1 A47 NUT M8X7T
1 A49 BEARING 6000 2RS
1 A50 EVA PAD STICKER 20*60*1.5T
2 A51 CLIP Φ18.5*Φ22.5*1T
1 A52 WASHER Φ20.3*Φ30*0.5T
1 A53 WAVE WASHER Φ20.5*Φ30*0.3T
1 A54 WAVE WASHER Φ10.2*Φ13*0.3T
1 A55 FIXING SHEET
1 A60 MOTOR
2 A61 SCREW
2 A62 SCREW
1 A63 NUT
2 A64 L-SHAPED BRACKET
1 A65 SCREW
1 A66 L-SHAPED BRACKET
1
A67 SCREW
1 B CENTRAL SUPPORT TUBE
1 B1 SENSOR WIRE 850mm
3 B2 SENSOR WIRE 350mm
1 B3 END CAP
EX60 TOUCH
Anz.
1
2
2
6
1
1
1
1
1
12
8
1
1
1
6
1
1
1
2
1
1
2
1
1
1
1
1
2
1
1
2
2
