Teileliste - CARDIOSTRONG EX80 Plus Touch Montage- Und Bedienungsanleitung

8.3

Teileliste

Nr. Bezeichnung (ENG)
A Main Frame
A1 Sensor Wire
A2 Connection Slice
A3 Motor
A3-1 Screw
A4 Dc Wire
A5 Nut
A6 Sensor Wire
A7 Sensor Wire Housing
A8 Screw
A9 Screw M8 X 45
A10 Nut M8
A11 Screw M6 X 20
A12 Nut M6
A13 End Cap
A14 Fix Cushiion
A15 Washer M6
A16 Screw M5 X 16
A17 Wheel
A18 Nut M8
A19 Screw M8 X 45
A20 Belt Wheel
A21 Magnetic
A22 Axle
A23 Screw M8 X 25
A24 Nut M8
A25 Bush
A26 Bearing 6005Zz
A27 Bush
A28 Bearing Nut
A29 Belt
Anz. Nr Bezeichnung (ENG)
1 A30 Crank
1 A31 Flat Key
2 A32 Screw
1 A33 Turing Plate
4 A34 Pressing Pipe
1 A35 Bearing 6003Zz
1 A36 C Lip
1 A37 Nut M12
1 A38 Washer M12
1 A39 Axle
1 A40 Bearing 6001Mrb
1 A41 Bush
1 A42 Flywheel
1 A43 Flywheel Cover
2 A44 Screw M4 X 16
2 A45 Magnetic Housing
2 A49 Screw M5 X 10
2 A50 Front Pedal Supporting Tube
2 A51 Magnetic
2 A52 Screw M5 X 8
2 A53 Induction Wand
1 A54 Side Decoration Housing Set ( L )
1 A55 Side Decoration Housing Set ( R )
1 A56 Screw
4 A57 Battery Cover
4 A58 Push Rod Bracket ( L )
1 A59 Push Rod Bracket ( R )
2 A60 Knob
1 A61 Nylon Sleeve
1 A62 Bolt M8 X 20
2 A63 Nut M8
Anz.
2
2
2
2
1
2
1
3
4
1
2
1
1
2
6
1
4
2
4
4
10
2
2
16
4
2
2
2
8
8
8
41
